| PartNumber | G215HAN01.4 |
| Znamka | AUO |
| Velikost | 21.5 |
| Aplikacija | Industrial Gaming |
| Resolucija | 1920×1080 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| ime modela | G215HAN01.4 |
| velikost zaslona | 21.5 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1920(RGB)×1080 (FHD) 102PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 476.064 × 267.786 (H×V) |
| obris (mm) | 497.6 × 292.2 × 11 (H×V×D) |
| površina okvirja (mm) | 479.8 × 271.3 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | - |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 12/10 (Typ.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M |
| osvetlitev ozadja | WLED , No Driver |
| masa | - |
| uporablja za | Industrial Gaming |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (2 ch, 8-bit) , Connector 30 pins |
| napajanje z napetostjo | 5.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
