| PartNumber | G190EAN01.6 |
| Znamka | AUO |
| Velikost | 19.0 |
| Aplikacija | Industrial Medical I |
| Resolucija | 1280×1024 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AUO |
| model | G190EAN01.6 |
| velikost diagonale | 19.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×1024 [SXGA] 86PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 376.32(H)×301.056(V) mm |
| obris dim. | 396(H)×324(V) ×15.8(D) mm |
| območje okvirja | 380.32(H)×305.06(V) mm |
| zdravljenje | Antiglare |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 13/12 (Typ.)(Tr/Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| način delovanja | AHVA, Normally Black, Transmissive |
| podpira barvo | 16.7M 72% NTSC |
| Izvor svetlobe | WLED , 50K hours , With LED Driver |
| utež | 1.70±0.15Kgs |
| namenjen za | Industrial Medical Imaging Outdoor High Brightness |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (2 ch, 8-bit) |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
