| PartNumber | G156HAN02.302 |
| Znamka | AUO |
| Velikost | 15.6 |
| Aplikacija | Industrial Medical I |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AUO |
| velikost diagonale | 15.6 inch |
| slikovnih pik | 1920(RGB)×1080 [FHD] 141PPI |
| aktivno območje | 344.16(H)×193.59(V) mm |
| območje okvirja | 347.06(H)×196.49(V) mm |
| svetilnost | 500 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 99% sRGB |
| utež | 600/660g (Typ./Max.) |
| hitrost sličic | 60Hz |
| tip vmesnika | LVDS (2 ch, 8-bit) , 30 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -20 ~ 70 °C |
| model | G156HAN02.302 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 363.8(H)×215.9(V) ×9.3(D) mm |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| način delovanja | AHVA, Normally Black, Transmissive |
| Izvor svetlobe | WLED , 50K hours , With LED Driver |
| namenjen za | Industrial Medical Imaging |
| plošča na dotik | Without |
