| PartNumber | G150XTN03.8 |
| Znamka | AUO |
| Velikost | 15.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| proizvajalec | AUO |
| velikost zaslona | 15.0 inch |
| število slikovnih pik | 1024(RGB)×768 (XGA) 85PPI |
| aktivna površina (mm) | 304.128 × 228.096 (H×V) |
| površina okvirja (mm) | 312.55 × 236.25 (H×V) |
| svetilnost | 400 cd/m² (Typ.) |
| vidni kot | 80/80/70/80 (Typ.)(CR≥10) |
| dober pogled na | - |
| barvna globina | 262K/16.2M 60% NTSC |
| masa | 720g (Max.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | eDP (1 Lane) , eDP1.2 , 30 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 60 °C |
| ime modela | G150XTN03.8 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| odgovor | 5.7/3.2 (Typ.)(Tr/Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
| G150X1-L02 | Innolux | 15.0 | 1024×768 |
| G150XG02 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XGE-L04 Rev.C4 | Innolux | 15.0 | 1024×768 |
| G150XGE-L05 | Innolux | 15.0 | 1024×768 |
| G150XGE-L07 | Innolux | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.1 | AUO | 15.0 | 1024×768 |
| G150XTT01.0 | AUO | 15.0 | 1024×768 |
