| PartNumber | G150XTN03.6 |
| Znamka | AUO |
| Velikost | 15.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| velikost zaslona | 15.0 inch |
| število slikovnih pik | 1024(RGB)×768 (XGA) 85PPI |
| aktivna površina (mm) | 304.128 × 228.096 (H×V) |
| površina okvirja (mm) | 313.55 × 237.25 (H×V) |
| svetilnost | 250 cd/m² (Typ.) |
| vidni kot | 45/45/20/40 (Typ.)(CR≥10) |
| dober pogled na | - |
| barvna globina | 262K/16.2M 60% NTSC |
| masa | 1.10Kgs (Max.) |
| hitrost osveževanja | 60Hz |
| vrsto signala | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 65 °C Operating Temp.: 0 ~ 65 °C |
| ime modela | G150XTN03.6 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 326.5 × 253.5 × 10 (H×V×D) |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 500 : 1 (Typ.) (TM) |
| odgovor | 5.7/2.3 (Typ.)(Tr/Td) ms |
| način dela | TN, Normally White, Transmissive |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| uporablja za | Industrial |
| zaslon na dotik | Without |
| G150X1-L01 | Innolux | 15.0 | 1024×768 |
| G150XG03 V0 | AUO | 15.0 | 1024×768 |
| G150XG03 V4 | AUO | 15.0 | 1024×768 |
| G150XG03 V5 | AUO | 15.0 | 1024×768 |
| G150XTN02.0 | AUO | 15.0 | 1024×768 |
| G150XTN03.2 | AUO | 15.0 | 1024×768 |
| G150XTN05.0 | AUO | 15.0 | 1024×768 |
| G150XTN06.2 | AUO | 15.0 | 1024×768 |
| G150XTN06.4 | AUO | 15.0 | 1024×768 |
| G150XVN01.0 | AUO | 15.0 | 1024×768 |
