| PartNumber | G150XAN01.2 |
| Znamka | AUO |
| Velikost | 15.0 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | AUO |
| ime modela | G150XAN01.2 |
| velikost zaslona | 15.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1024(RGB)×768 (XGA) 85PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 304.128 × 228.096 (H×V) |
| obris (mm) | 326.5 × 253.5 × 6.8 (H×V×D) |
| površina okvirja (mm) | 309.9 × 236.3 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 25 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.2M 60% NTSC |
| osvetlitev ozadja | WLED , 50K hours , With LED Driver |
| masa | 660g (Max.) |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 8-bit) , Connector 30 pins |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 70 °C Operating Temp.: -20 ~ 70 °C |
