| PartNumber | G104STN01.4 |
| Znamka | AUO |
| Velikost | 10.4 |
| Aplikacija | Industrial |
| Resolucija | 800×600 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AUO |
| model | G104STN01.4 |
| velikost diagonale | 10.4 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 800(RGB)×600 [SVGA] 96PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 211.2(H)×158.4(V) mm |
| obris dim. | - |
| svetilnost | - |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| smer pogleda | - |
| odzivni čas | - |
| vidni kot | 80/80/60/70 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K/16.2M |
| Izvor svetlobe | WLED |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 6/8-bit) |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
| G104S1-L01 | Innolux | 10.4 | 800×600 |
| G104SN02 V0 | AUO | 10.4 | 800×600 |
| G104SN02 V1 | AUO | 10.4 | 800×600 |
| G104SN02 V2 | AUO | 10.4 | 800×600 |
| G104SN03 V0 | AUO | 10.4 | 800×600 |
| G104SN03 V1 | AUO | 10.4 | 800×600 |
| G104SN03 V4 | AUO | 10.4 | 800×600 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| G104SN05 V0 | AUO | 10.4 | 800×600 |
| G104STN01.0 | AUO | 10.4 | 800×600 |
