| PartNumber | G101STN01.5 |
| Znamka | AUO |
| Velikost | 10.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| znamka | AUO |
| velikost diagonale | 10.1 inch |
| slikovnih pik | 1024(RGB)×600 [WSVGA] 117PPI |
| aktivno območje | 222.72(H)×125.28(V) mm |
| območje okvirja | 226.43(H)×128.1(V) mm |
| svetilnost | 350 cd/m² (Typ.) |
| smer pogleda | - |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.7M 45% NTSC |
| utež | 340g (Max.) |
| hitrost sličic | 60Hz |
| tip vmesnika | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| napajanje | 3.3/10/18/-8V (Typ.)(VDD/AVDD/VGH/VGL) |
| okolju | Operating Temperature: -10 ~ 60 °C ; Storage Temperature: -30 ~ 70 °C |
| model | G101STN01.5 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 235(H)×143(V) ×5.5(D) mm |
| zdravljenje | Antiglare, Hard coating (3H) |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| odzivni čas | 7/9 (Typ.)(Tr/Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED , 15K hours , W/O Driver |
| namenjen za | Industrial |
| plošča na dotik | Without |
