| PartNumber | F-51430NFU-FW-AA |
| Znamka | Kyocera |
| Velikost | 9.4 |
| Aplikacija | IA |
| Resolucija | 640×480 |
| Sestava | LCM |
| Svetlost | 110 |
| CR | 14:1 |
| Barve | Monochrome |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | OPTREX |
| panelni model | F-51430NFU-FW-AA |
| vrsta plošče | FSTN-LCD , LCM |
| velikost plošče | 9.4 inch |
| resolucija | 640×480 , VGA |
| način prikaza | STN, Black/White mode, Transmissive |
| aktivno območje | 191.97×143.97 mm |
| oris | 260×174×8.5 mm |
| površino | |
| svetlost | 110 cd/m² (Typ.) |
| kontrastno razmerje | 14:1 (Typ.) |
| barve zaslona | Monochrome (1-bit) |
| odzivni čas | 210/120 (Typ.)(Tr/Td) |
| vidni kot | 60/60/23/32 (Typ.)(CR≥2)(L/R/U/D) |
| pogostost | 70Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (2ch, 4-bit), 15 pins |
| vhodna napetost | 2.5/5.5V (Min./Max.) |
| aplikacija | IA |
| AA084XE11 | Mitsubishi | 8.4 | 1024×768 |
| AC150XA02 | Mitsubishi | 15.0 | 1024×768 |
| EL320.240.36 AGL | Lumineq | 5.7 | 320×240 |
| G070VTT01.0 | AUO | 7.0 | 800×480 |
| G104SN03 V5 | AUO | 10.4 | 800×600 |
| KS3224ASTT-FW-X2 | Kyocera | 5.7 | 320×240 |
| LMG7420PLFC | KOE | 5.1 | 240×128 |
| LQ10D368 | SHARP | 10.4 | 640×480 |
| OEL9M0064-R-E | Other | 2.0 | 128×32 |
| TX17D200VM0BAA | KOE | 6.5 | 800×480 |
