| PartNumber | ET104S0M-N11 |
| Znamka | BOE |
| Velikost | 10.4 |
| Aplikacija | Industrial |
| Resolucija | 800×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | BOE |
| velikost diagonale | 10.4 inch |
| slikovnih pik | 800(RGB)×600 [SVGA] 96PPI |
| aktivno območje | 211.2(H)×158.4(V) mm |
| območje okvirja | 215(H)×162(V) mm |
| svetilnost | 350 cd/m² (Typ.) |
| smer pogleda | 12 o'clock |
| vidni kot | 80/80/65/75 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.2M 55% NTSC |
| utež | 288g (Typ.) |
| hitrost sličic | 60Hz |
| tip vmesnika | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | ET104S0M-N11 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 236(H)×176.9(V) ×5.9(D) mm |
| zdravljenje | Antiglare (Haze 25%) |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED , 30K hours , W/O Driver |
| namenjen za | Industrial |
| plošča na dotik | Without |
