| PartNumber | ER057005NC6 |
| Znamka | EDT |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | LCM |
| Svetlost | 150 |
| CR | 50:1 |
| Barve | Color |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel Data |
| znamka plošče | EDT |
| panelni model | ER057005NC6 |
| vrsta plošče | CSTN-LCD , LCM |
| velikost plošče | 5.7 inch |
| resolucija | 320(RGB)×240 , QVGA |
| način prikaza | STN, Normally Black, Transmissive |
| aktivno območje | 115.2×86.4 mm |
| oris | 167×109×9.4 mm |
| površino | |
| svetlost | 150 cd/m² (Typ.) |
| kontrastno razmerje | 50:1 (Typ.) |
| barve zaslona | Color |
| odzivni čas | 350/250 (Typ.)(Tr/Td) |
| vidni kot | 40/40/20/40 (Typ.)(CR≥2)(L/R/U/D) |
| pogostost | 120Hz |
| tip svetilke | 1 pcsCCFLWithout Driver |
| signalni vmesnik | Parallel Data (8-bit), 16 pins |
| vhodna napetost | 3.3/5.0V (Typ.)(VDD) |
| aplikacija | IA |
