| PartNumber | EL320.240.36 HB NE |
| Znamka | PLANAR |
| Velikost | 5.7 |
| Aplikacija | IA |
| Resolucija | 320×240 |
| Sestava | EL |
| Svetlost | 150 |
| CR | 90:1 |
| Barve | Mono(Yellow) |
| Osvetlitev ozadja | self |
| Vmesnik | Parallel Data |
| znamka plošče | PLANAR |
| panelni model | EL320.240.36 HB NE |
| vrsta plošče | EL , EL |
| velikost plošče | 5.7 inch |
| resolucija | 320×240 , QVGA |
| aktivno območje | 115.1×86.3 mm |
| oris | 148.1×104.7 mm |
| površino | |
| svetlost | 150 cd/m² (Typ.) |
| kontrastno razmerje | 90 : 1 (Typ.) |
| barve zaslona | Mono(Yellow) (1-bit) |
| vidni kot | 89/89/89/89 (Typ.)(L/R/U/D) |
| pogostost | 120Hz |
| signalni vmesnik | Parallel Data (1ch, 4-bit), 26 pins |
| vhodna napetost | 5/12V (Typ.)(VL/VH) |
| aplikacija | IA |
