| PartNumber | DMF-50174 |
| Znamka | OPTREX |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | STN-LCD, LCM |
| Svetlost | |
| CR | |
| Barve | Monochrome |
| Osvetlitev ozadja | CCFL |
| Vmesnik | Parallel |
| znamka | OPTREX |
| model | DMF-50174 |
| velikost diagonale | 5.7 inch |
| vrsta | STN-LCD, LCM |
| slikovnih pik | 320×240 [QVGA] 70PPI |
| konfiguracijo | Rectangle |
| aktivno območje | 115.17(H)×86.37(V) mm |
| obris dim. | 174(H)×112(V) ×14(D) mm |
| območje okvirja | 122.0(H)×92.0(V) mm |
| zdravljenje | - |
| smer pogleda | - |
| odzivni čas | - |
| vidni kot | - |
| način delovanja | STN |
| podpira barvo | Monochrome |
| Izvor svetlobe | CCFL , W/O Driver |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 70Hz |
| plošča na dotik | Without |
| tip vmesnika | Parallel Data (1ch, 4-bit) , 14 pins Connector |
| napajanje | 5.0V (Typ.) |
| okolju | Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
