| PartNumber | DBT070CTV50R9 |
| Znamka | No Brand |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | No Brand |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 800(RGB)×480 [WVGA] 134PPI |
| aktivno območje | 154.08(H)×85.92(V) mm |
| območje okvirja | 157(H)×89.5(V) mm |
| svetilnost | 1000 cd/m² (Typ.) |
| smer pogleda | - |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| podpira barvo | 16.7M |
| utež | TBD |
| hitrost sličic | 60Hz |
| model | DBT070CTV50R9 |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 165(H)×100(V) mm |
| zdravljenje | Antiglare |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| način delovanja | TN, Normally White, Transmissive |
| Izvor svetlobe | WLED , 20K hours , W/O Driver |
| namenjen za | Industrial Outdoor High Brightness |
| plošča na dotik | Without |
| AT070TN83 | Innolux | 7.0 | 800×480 |
| AT070TN83 V.1 | Innolux | 7.0 | 800×480 |
| AT070TN94 | Innolux | 7.0 | 800×480 |
| C070VW02 V1 | AUO | 7.0 | 800×480 |
| G070VVN01.0 | AUO | 7.0 | 800×480 |
| LMS700KF07 | Samsung | 7.0 | 800×480 |
| LQ070T1LG01 | SHARP | 7.0 | 800×480 |
| LQ070Y5DG30 | SHARP | 7.0 | 800×480 |
| PM070WL3 | E Ink | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
