| PartNumber | CT035TN02 |
| Znamka | Innolux |
| Velikost | 3.5 |
| Aplikacija | MPH |
| Resolucija | 320×480 |
| Sestava | LCM |
| Svetlost | 320 |
| CR | 500:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU/RGB/SPI |
| znamka plošče | CHIMEI INNOLUX |
| panelni model | CT035TN02 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 3.5 inch |
| resolucija | 320(RGB)×480 , HVGA |
| način prikaza | IPS, Normally Black, Transmissive |
| aktivno območje | 48.96×73.44 mm |
| oris | 54.76×85.24×2.1 mm |
| površino | |
| svetlost | 320 cd/m² (Typ.) |
| kontrastno razmerje | 500:1 (Typ.) |
| barve zaslona | 65K/262K , CIE193170% |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 1S5PWLEDWithout Driver |
| signalni vmesnik | CPU/RGB/SPI, 50 pins |
| vhodna napetost | 2.8/2.8V (Typ.)(VDD3/VCI) |
| aplikacija | MPH |
