| PartNumber | COM70T7M17ZLC |
| Znamka | ORTUSTECH |
| Velikost | 7.0 |
| Aplikacija | IA |
| Resolucija | 800×480 |
| Sestava | LCM |
| Svetlost | 530 |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | TTL |
| znamka plošče | ORTUSTECH |
| panelni model | COM70T7M17ZLC |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.0 inch |
| resolucija | 800(RGB)×480 , WVGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 152.4×91.44 mm |
| oris | 165×105.8×3.65 mm |
| površino | Hard coating (3H) |
| svetlost | 530 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) |
| barve zaslona | 262K (6-bit) |
| odzivni čas | 40/60 (Max.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 8S3PWLEDWithout Driver |
| signalni vmesnik | Parallel RGB (1 ch, 6-bit), 40 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
