| PartNumber | CM546B2-001 |
| Znamka | CSOT |
| Velikost | 5.5 |
| Aplikacija | Mobile Phone |
| Resolucija | 1080×1920 |
| Sestava | LTPS TFT-LCD, CELL |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | No |
| Vmesnik | |
| znamka plošče | CSOT |
| panelni model | CM546B2-001 |
| velikost plošče | 5.5" |
| vrsta plošče | LTPS TFT-LCD, CELL |
| resolucija | 1080(RGB)×1920, FHD, 403PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 68.04(W)×120.96(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 69.44(W)×126.81(H) ×0.45(D) mm |
| površino | With Polarizer |
| svetlost | 0 cd/m² |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način prikaza | FFS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 35 (Typ.)(Tr+Td) |
| globina stekla | 0.15+0.15 mm |
| transmisivnost | 4.69% (Typ.)(with APCF) |
| barve zaslona | 16.7M 80% NTSC |
| tip svetilke | No B/L |
| pogostost | - |
| zaslon na dotik | In-Cell Touch |
| voznik ic | COG Built-in TD4310 |
| teža plošče | TBD |
| aplikacija | Mobile Phone |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
