| PartNumber | CLAA123PA02CW |
| Znamka | CPT |
| Velikost | 12.3 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1440×540 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | CPT |
| model | CLAA123PA02CW |
| velikost diagonale | 12.3 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1440(RGB)×540 125PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 291.6(H)×109.35(V) mm |
| obris dim. | 312.9(H)×132.2(V) ×19.2(D) mm |
| območje okvirja | 294.8(H)×112.4(V) mm |
| zdravljenje | Antiglare (Haze 25%) |
| svetilnost | 800 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 60/60/50/60 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 16.7M 70% NTSC |
| Izvor svetlobe | WLED [8S3P] , 30K hours , W/O Driver |
| utež | 510g (Typ.) |
| namenjen za | Industrial Outdoor High Brightness Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 8-bit) , 30 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
