| PartNumber | CLAA101WK07 XN |
| Znamka | CPT |
| Velikost | 10.1 |
| Aplikacija | Automotive Display |
| Resolucija | 1280×720 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | CPT |
| velikost diagonale | 10.1 inch |
| slikovnih pik | 1280(RGB)×720 [WXGA] 144PPI |
| aktivno območje | 224.64(H)×126.36(V) mm |
| območje okvirja | 227.64(H)×129.36(V) mm |
| svetilnost | 600 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| podpira barvo | 262K/16.7M 70% NTSC |
| utež | 430g (Typ.) |
| hitrost sličic | 60Hz |
| model | CLAA101WK07 XN |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 238.8(H)×148.05(V) ×8.7(D) mm |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| način delovanja | HFFS, Normally Black, Transmissive |
| Izvor svetlobe | WLED [6S5P] , 30K hours , W/O Driver |
| namenjen za | Automotive Display |
| plošča na dotik | Without |
