| PartNumber | CLAA080WQ05 XN |
| Znamka | CPT |
| Velikost | 8.0 |
| Aplikacija | Pad & Tablet Industr |
| Resolucija | 800×1280 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 3S7P |
| Vmesnik | |
| proizvajalec | CPT |
| velikost zaslona | 8.0 inch |
| število slikovnih pik | 800(RGB)×1280 (WXGA) 188PPI |
| aktivna površina (mm) | 107.64 × 172.224 (H×V) |
| površina okvirja (mm) | - |
| svetilnost | 350 (Typ.)(cd/m²) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M 58% NTSC |
| masa | 115g (Max.) |
| hitrost osveževanja | 60Hz |
| ime modela | CLAA080WQ05 XN |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Vertical Stripe |
| obris (mm) | 114.6 × 184.7 × 4.56 (H×V×D) |
| zdravljenje | Hard coating (3H) |
| kontrastno razmerje | 800 : 1 (Typ.) (TM) |
| način dela | HFFS, Normally Black, Transmissive |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| osvetlitev ozadja | 3S7P WLED , 15K hours , No Driver |
| uporablja za | Pad & Tablet Industrial |
| zaslon na dotik | Without |
| CLAA080JA11CW | CPT | 8.0 | 480×220 |
| CLAA080LA0ACW | CPT | 8.0 | 800×480 |
| CLAA080LA0BCW | CPT | 8.0 | 800×480 |
| CLAA080LB0AXV | CPT | 8.0 | 800×480 |
| CLAA080LG01CW | CPT | 8.0 | 800×480 |
| CLAA080MB0DCW | CPT | 8.0 | 800×600 |
| CLAA080NA01 CW | CPT | 8.0 | 1024×600 |
| CLAA080UA01 | CPT | 8.0 | 1600×768 |
| CLAA080WQ02 XG | CPT | 8.0 | 800×1280 |
| CLAA080WQ08 XN | CPT | 8.0 | 800×1280 |
