| PartNumber | CLAA080WK0A XN |
| Znamka | CPT |
| Velikost | 8.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1280×720 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | CPT |
| model | CLAA080WK0A XN |
| velikost diagonale | 8.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1280(RGB)×720 [WXGA] 183PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 177.024(H)×99.576(V) mm |
| obris dim. | 182.8(H)×116.9(V) ×6.8(D) mm |
| območje okvirja | 179.024(H)×101.576(V) mm |
| zdravljenje | Antiglare (Haze 25%), Hard coating (3H) |
| svetilnost | 600 cd/m² (Typ.) |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način delovanja | HFFS, Normally Black, Transmissive |
| podpira barvo | 16.7M 70% NTSC |
| Izvor svetlobe | WLED [9S3P] , 50K hours , W/O Driver |
| utež | 120/230g (Typ./Max.) |
| namenjen za | Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| Operating Temperature: -40 ~ 85 °C ; Storage Temperature: -40 ~ 90 °C ; Vibration Level: 2.9G (28.4 m/s²) |
