| PartNumber | CLAA070WQ62 XG |
| Znamka | CPT |
| Velikost | 7.0 |
| Aplikacija | Pad & Tablet |
| Resolucija | 800×1280 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka | CPT |
| velikost diagonale | 7.0 inch |
| slikovnih pik | 800(RGB)×1280 [WXGA] 215PPI |
| aktivno območje | 94.2(H)×150.72(V) mm |
| območje okvirja | - |
| svetilnost | 350 cd/m² (Typ.) |
| smer pogleda | Symmetry |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| podpira barvo | 16.7M 70% NTSC |
| utež | - |
| hitrost sličic | 60Hz |
| tip vmesnika | MIPI (4 data lanes) , 39 pins FPC |
| napajanje | 1.8/3.3/15/-10V (Typ.)(VDDI/VCI/VGH/VGL) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C ; Vibration Level: 2.9G (28.4 m/s²) |
| model | CLAA070WQ62 XG |
| vrsta | a-Si TFT-LCD , LCM |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 99.6(H)×161.62(V) ×4.05(D) mm |
| zdravljenje | Hard coating |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| način delovanja | FFS, Normally Black, Transmissive |
| Izvor svetlobe | WLED [3S6P] , 15K hours , W/O Driver |
| namenjen za | Pad & Tablet |
| plošča na dotik | On-Cell Touch |
| CLAA070LF05CW | CPT | 7.0 | 800×480 |
| CLAA070LFA1 CW | CPT | 7.0 | 800×480 |
| CLAA070MA32BW | CPT | 7.0 | 800×600 |
| CLAA070NB02CT | CPT | 7.0 | 1024×600 |
| CLAA070NC0BCT | CPT | 7.0 | 1024×600 |
| CLAA070ND02 | CPT | 7.0 | 1024×600 |
| CLAA070NJ01CW | CPT | 7.0 | 1024×600 |
| CLAA070NJ05CW | CPT | 7.0 | 1024×600 |
| CLAA070NP01HXG | CPT | 7.0 | 1024×600 |
| CLAA070WP06G XG | CPT | 7.0 | 800×1280 |
