| PartNumber | CC580PV5D |
| Znamka | PANDA |
| Velikost | 58 |
| Aplikacija | TV Sets |
| Resolucija | 3840×2160 |
| Sestava | Oxide TFT-LCD , CELL |
| Svetlost | |
| CR | 6000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | |
| znamka | PANDA |
| velikost diagonale | 58 inch |
| slikovnih pik | 3840(RGB)×2160 [UHD] 76PPI |
| aktivno območje | 1270.08(H)×721.44(V) mm |
| območje okvirja | - |
| svetilnost | 0 cd/m² |
| smer pogleda | Symmetry |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| debelina plošče | 0.50+0.50 mm |
| podpira barvo | 1.07B 70% NTSC |
| utež | 2.84Kgs (Typ.) |
| hitrost sličic | 60Hz |
| model | CC580PV5D |
| vrsta | Oxide TFT-LCD , CELL |
| konfiguracijo | RGB Vertical Stripe |
| obris dim. | 1282.88(H)×734.44(V) ×1.36(D) mm |
| zdravljenje | Antiglare, Hard coating (2H) |
| kontrastno razmerje | 6000:1 (Typ.) (TM) |
| odzivni čas | 8 (Typ.)(G to G) |
| način delovanja | UV2A, Normally Black, Transmissive |
| prepustnost | 5.5% (Typ.)(with Polarizer) |
| Izvor svetlobe | No B/L |
| namenjen za | TV Sets |
| plošča na dotik | Without |
| LK580Z3LA13 | SHARP | 58 | 2560×1080 |
| V580DJ2-QS5 | Innolux | 58 | 3840×2160 |
| V580DK1-QS2 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 | Innolux | 58 | 3840×2160 |
| V580DK2-KS1 Rev.C8 | Innolux | 58 | 3840×2160 |
| V580HJ1-LD6 | Innolux | 58 | 1920×1080 |
| V580HJ1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LD6 | Innolux | 58 | 1920×1080 |
| V580HK1-LE6 | Innolux | 58 | 1920×1080 |
| V580HK1-LS6 | Innolux | 58 | 1920×1080 |
