| PartNumber | CC500PV1D |
| Znamka | PANDA |
| Velikost | 50 |
| Aplikacija | TV Sets |
| Resolucija | 3840×2160 |
| Sestava | CELL, Oxide TFT-LC |
| Svetlost | |
| CR | 5000:1 |
| Barve | 1.07B |
| Osvetlitev ozadja | No |
| Vmesnik | V-by-One |
| proizvajalec | PANDA |
| ime modela | CC500PV1D |
| velikost zaslona | 50 inch |
| vrsto zaslona | CELL, Oxide TFT-LCD |
| število slikovnih pik | 3840(RGB)×2160 (UHD) 89PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 1095.8 × 616.41 (H×V) |
| obris (mm) | 1106.84 × 628.01 × 1.37 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Hard coating (2H) |
| svetilnost | 0 cd/m² |
| kontrastno razmerje | 5000 : 1 (Typ.) (TM) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10) |
| odgovor | 8 (Typ.)(G to G) ms |
| dober pogled na | Symmetry |
| način dela | UV2A, Normally Black, Transmissive |
| debelina stekla | 0.50+0.50 mm |
| transmisivnost | 5.2% (Typ.)(with Polarizer) |
| barvna globina | 1.07B 70% NTSC |
| osvetlitev ozadja | No B/L |
| masa | 2.12Kgs (Typ.) |
| uporablja za | TV Sets |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| seznam gonilnikov ic | Built-in COF 12 source chips |
| vrsto signala | V-by-One 8 lane , Connector 51 pins |
| napajanje z napetostjo | 12.0V (Typ.) |
| maks. ocene | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
