| PartNumber | C100HAT01.0 |
| Znamka | AUO |
| Velikost | 10.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1560×700 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | AUO |
| ime modela | C100HAT01.0 |
| velikost zaslona | 10.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1560(RGB)×700 171PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 231.66 × 103.95 (H×V) |
| obris (mm) | 259.36 × 131.32 (H×V×D) |
| površina okvirja (mm) | - |
| zdravljenje | Antiglare, Antireflection |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 30 (Max.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M |
| osvetlitev ozadja | WLED |
| masa | 375±38g |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | - |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C |
