| PartNumber | C084SAT01.1 |
| Znamka | AUO |
| Velikost | 8.4 |
| Aplikacija | Automotive Display |
| Resolucija | 800×600 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| proizvajalec | AUO |
| velikost zaslona | 8.4 inch |
| število slikovnih pik | 800×600(RGB) (SVGA) 118PPI |
| aktivna površina (mm) | 170.88 × 128.16 (H×V) |
| svetilnost | - |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| dober pogled na | Symmetry |
| barvna globina | 16.7M |
| masa | - |
| hitrost osveževanja | 60Hz |
| maks. ocene | Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 90 °C |
| ime modela | C084SAT01.1 |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| ureditev | RGB Horizontal Stripe |
| obris (mm) | - |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| odgovor | 15/20 (Typ.)(Tr/Td) ms |
| način dela | AHVA, Normally Black, Transmissive |
| osvetlitev ozadja | WLED , No Driver |
| uporablja za | Automotive Display |
| zaslon na dotik | Without |
| AA084SB11 | Mitsubishi | 8.4 | 800×600 |
| AA084SD11 | Mitsubishi | 8.4 | 800×600 |
| AA084XA03 | Mitsubishi | 8.4 | 1024×768 |
| G084SN03 V1 | AUO | 8.4 | 800×600 |
| M084GNS1 R1 | IVO | 8.4 | 800×600 |
| NL10276BC16-01 | NLT | 8.4 | 1024×768 |
| NL6448BC26-01 | NLT | 8.4 | 640×480 |
| T-51639D084JU-FW-A-AB | Kyocera | 8.4 | 1024×768 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
