| PartNumber | C080EAN04.1 |
| Znamka | AUO |
| Velikost | 8.0 |
| Aplikacija | Automotive Display |
| Resolucija | 1280×720 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 6S4P |
| Vmesnik | |
| proizvajalec | AUO |
| ime modela | C080EAN04.1 |
| velikost zaslona | 8.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1280(RGB)×720 (WXGA) 184PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 176.64 × 99.36 (H×V) |
| obris (mm) | 186.5 × 117.12 (H×V×D) |
| površina okvirja (mm) | 179.55 × 105.36 (H×V) |
| zdravljenje | Antiglare |
| svetilnost | 750 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| odgovor | 20 (Max.)(Tr+Tf) ms |
| dober pogled na | Symmetry |
| način dela | AHVA, Normally Black, Transmissive |
| barvna globina | 16.7M 68% NTSC |
| osvetlitev ozadja | 6S4P WLED , 30K hours , No Driver |
| masa | 229±23g |
| uporablja za | Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -40 ~ 95 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 2.9G (28.4 m/s²) |
