| PartNumber | B156HTN05.1 |
| Znamka | AUO |
| Velikost | 15.6 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka | AUO |
| model | B156HTN05.1 (AUO51ED) |
| velikost diagonale | 15.6 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1920(RGB)×1080 [FHD] 141PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 344.16(H)×193.59(V) mm |
| obris dim. | 359.5(H)×223.8(V) ×3.2(D) mm |
| območje okvirja | - |
| zdravljenje | Antiglare |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 5 (Typ.)(Tr+Td) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 72% NTSC |
| Izvor svetlobe | WLED , 16K hours , With LED Driver |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| namenjen za | Laptop |
| hitrost sličic | 120Hz |
| plošča na dotik | Without |
| Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C |
