| PartNumber | B140HAN06.0 |
| Znamka | AUO |
| Velikost | 14.0 |
| Aplikacija | Laptop |
| Resolucija | 1920×1080 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 1500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | eDP |
| znamka plošče | AUO |
| velikost plošče | 14.0" |
| resolucija | 1920(RGB)×1080, FHD, 157PPI |
| prikazno območje | 309.37(W)×174.02(H) mm |
| velikost obrisa | 313.67(W)×183.37(H) ×2(D) mm |
| svetlost | 300 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 100% sRGB |
| pogostost | 60Hz |
| slog oblike | Slim (PCBA Flat, T≤3.2mm) |
| signalni vmesnik | eDP (2 Lanes) , eDP1.4 , 30 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panelni model | B140HAN06.0 (AUO603D) |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Glare (Haze 0%), Hard coating (1H) |
| kontrastno razmerje | 1500:1 (Typ.) (TM) |
| način prikaza | AHVA, Normally Black, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| tip svetilke | WLED , 15K hours , With LED Driver |
| zaslon na dotik | Without |
| aplikacija | Laptop |
| B140HAN01.0 | AUO | 14.0 | 1920×1080 |
| B140HAN01.1 | AUO | 14.0 | 1920×1080 |
| B140HAN01.2 | AUO | 14.0 | 1920×1080 |
| B140HAN01.3 | AUO | 14.0 | 1920×1080 |
| B140HAN01.8 | AUO | 14.0 | 1920×1080 |
| B140HAT02.0 | AUO | 14.0 | 1920×1080 |
| B140HTN01.1 | AUO | 14.0 | 1920×1080 |
| B140HTN01.3 | AUO | 14.0 | 1920×1080 |
| M140NWR4 R2 | IVO | 14.0 | 1366×768 |
| N140BGE-L12 | Innolux | 14.0 | 1366×768 |
