| PartNumber | B079XAN01.0 |
| Znamka | AUO |
| Velikost | 7.9 |
| Aplikacija | PAD |
| Resolucija | 768×1024 |
| Sestava | LCM |
| Svetlost | 400 |
| CR | 800:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | MIPI |
| znamka plošče | AUO |
| panelni model | B079XAN01.0 1 Compatible model |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 7.9 inch |
| resolucija | 768(RGB)×1024 , XGA |
| način prikaza | AHVA, Normally Black, Transmissive |
| aktivno območje | 119.808×159.744 mm |
| oris | 129×171.07×4.81 mm |
| površino | |
| svetlost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 800:1 (Typ.) |
| barve zaslona | 262K (6-bit), CIE193150% |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| vidni kot | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | 6 stringsWLEDWithout Driver |
| signalni vmesnik | MIPI (4 data lanes), 32 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | PAD |
| B079XAN01.0 | AUO | 7.9 | 768×1024 |
| B101EW05 V1 | AUO | 10.1 | 1280×800 |
| B101UAN01.7 HW1A | AUO | 10.1 | 1920×1200 |
| BP101WX1-100 | BOE | 10.1 | 1280×800 |
| CLAA070WP06 XG | CPT | 7.0 | 800×1280 |
| HSD101PWW1-A00 Rev.4 | HannStar | 10.1 | 1280×800 |
| HSD101PWW2-A00 | HannStar | 10.1 | 1280×800 |
| LD070WU2-SH01 | LG Display | 7.0 | 1200×1920 |
| LP097X02-SLA3 | LG Display | 9.7 | 1024×768 |
| LTL070AL03 | Samsung | 7.0 | 800×1280 |
