| PartNumber | AT104XH11 |
| Znamka | Mitsubishi |
| Velikost | 10.4 |
| Aplikacija | IA |
| Resolucija | 1024×768 |
| Sestava | LCM |
| Svetlost | 1200 |
| CR | 700:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | Mitsubishi |
| panelni model | AT104XH11 |
| vrsta plošče | a-Si TFT-LCD , LCM |
| velikost plošče | 10.4 inch |
| resolucija | 1024(RGB)×768 , XGA |
| način prikaza | TN, Normally White, Transmissive |
| aktivno območje | 210.4×157.8 mm |
| oris | 230.2×180.2 mm |
| površino | Antiglare, Hard coating (3H) |
| svetlost | 1200 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) |
| barve zaslona | 262K/16.7M (6-bit / 6-bit + Hi-FRC), CIE193140% |
| odzivni čas | 4/12 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| pogostost | 60Hz |
| tip svetilke | WLEDWithout Driver |
| signalni vmesnik | LVDS (1 ch, 6/8-bit), 20 pins |
| vhodna napetost | 3.3V (Typ.) |
| aplikacija | IA |
| AA104XG12 | Mitsubishi | 10.4 | 1024×768 |
| AT101WSM-NW0-3800(3900) | BOE | 10.1 | 1024×600 |
| AT102TN03 V.1 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.3 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.8 | Innolux | 10.2 | 800×480 |
| AT102TN03 V.9 | Innolux | 10.2 | 800×480 |
| AT102TN42 | Innolux | 10.2 | 1024×600 |
| AT104XH11 | Mitsubishi | 10.4 | 1024×768 |
| CLAA104XA01CW | CPT | 10.4 | 1024×768 |
| PD104VT3 | E Ink | 10.4 | 640×480 |
| AA104XD02 | Mitsubishi | 10.4 | 1024×768 |
| DLH1095 | LiteMax | 10.4 | 1024×768 |
| EL480.60.43 CC | PLANAR | 8.1 | 480×60 |
| G190SVT01.0 | AUO | 19.0 | 1680×342 |
| LQ104S1DG21 | SHARP | 10.4 | 800×600 |
| LQ150X1LG11 | SHARP | 15.0 | 1024×768 |
| LTA104D183F | TOSHIBA | 10.4 | 800×600 |
| OEL9M0073-G-E | Other | 1.0 | 128×64 |
| OEL9M0078-W-E | Other | 1.45 | 132×16 |
| TM057KDH02 | Tianma | 5.7 | 320×240 |
