| PartNumber | AT070MP11 |
| Znamka | Mitsubishi |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| proizvajalec | Mitsubishi |
| ime modela | AT070MP11 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| obris (mm) | 169.8 × 109.7 × 9.4 (H×V×D) |
| površina okvirja (mm) | 154.4 × 93.5 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 1300 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 4/12 (Typ.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | SWV, Normally Black, Transmissive |
| barvna globina | 262K/16.7M 50% NTSC |
| osvetlitev ozadja | WLED , 100K hours , No Driver |
| masa | 200g |
| uporablja za | Industrial Outdoor High Brightness Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| vrsto signala | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje z napetostjo | 3.3V (Typ.) |
| maks. ocene | Storage Temp.: -40 ~ 85 °C Operating Temp.: -40 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
