| PartNumber | AT043TN14 V.1 |
| Znamka | Innolux |
| Velikost | 4.3 |
| Aplikacija | Portable Navigation |
| Resolucija | 480×272 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 500:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| znamka | Innolux |
| model | AT043TN14 V.1 |
| velikost diagonale | 4.3 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 480(RGB)×272 [WQVGA] 128PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 95.04(H)×53.856(V) mm |
| obris dim. | - |
| območje okvirja | - |
| zdravljenje | Antiglare |
| svetilnost | - |
| kontrastno razmerje | 500:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 10/15 (Typ.)(Tr/Td) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 16.7M |
| Izvor svetlobe | WLED |
| utež | - |
| namenjen za | Portable Navigation MP3 PMP |
| hitrost sličic | - |
| plošča na dotik | 4-wire Resistive Touch |
| tip vmesnika | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| napajanje | (2.5/3.3)/5.0V (Typ.)(VDD/AVDD) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
