| PartNumber | AM800480R3TMQW-B2H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM800480R3TMQW-B2H |
| velikost diagonale | 7.0 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 800(RGB)×480 [WVGA] 133PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 152.4(H)×91.44(V) mm |
| obris dim. | - |
| svetilnost | - |
| kontrastno razmerje | 400:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| vidni kot | 70/70/60/70 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K 45% NTSC |
| Izvor svetlobe | WLED |
| utež | - |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | LVDS (1 ch, 8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
