| PartNumber | AM480272H3TMQW-TW1H |
| Znamka | AMPIRE |
| Velikost | 4.3 |
| Aplikacija | Industrial |
| Resolucija | 480×272 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 250:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | WLED |
| Vmesnik | 8/9/16/18-bit |
| znamka | AMPIRE |
| model | AM480272H3TMQW-TW1H |
| velikost diagonale | 4.3 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 480(RGB)×272 [WQVGA] 128PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 95.04(H)×53.856(V) mm |
| obris dim. | 105.5(H)×67.2(V) ×7.91(D) mm |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 250:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 15/35 (Typ.)(Tr/Td) |
| vidni kot | 70/70/35/55 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 65K/262K 52% NTSC |
| Izvor svetlobe | WLED [7S1P] , 15K hours , W/O Driver |
| utež | TBD |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | 4-wire Resistive Touch |
| tip vmesnika | 8/9/16/18-bit 6800/8080 parallel , 40 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
