| PartNumber | AM-800600MTMQW-50H |
| Znamka | AMPIRE |
| Velikost | 8.4 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 800×600 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 6S5P |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 8.4" |
| resolucija | 800(RGB)×600, SVGA, 119PPI |
| prikazno območje | 170.4(W)×127.8(H) mm |
| velikost obrisa | 189.75(W)×149.4(H) ×5.3(D) mm |
| svetlost | 1000 cd/m² (Typ.) |
| vidni kot | 75/75/60/70 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M |
| pogostost | 60Hz |
| utež | TBD |
| panelni model | AM-800600MTMQW-50H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | 173.4(W)×130.8(H) mm |
| površino | - |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 8 (Typ.)(Tr+Td) |
| tip svetilke | 6S5P WLED , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial Outdoor High Brightness |
