| PartNumber | AM-800600MGTMQW-02H |
| Znamka | AMPIRE |
| Velikost | 8.4 |
| Aplikacija | Industrial |
| Resolucija | 800×600 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 12S4P |
| Vmesnik | LVDS |
| znamka plošče | AMPIRE |
| panelni model | AM-800600MGTMQW-02H |
| velikost plošče | 8.4" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 800(RGB)×600, SVGA, 119PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 170.4(W)×127.8(H) mm |
| odprtina okvirja | 174.15(W)×131.2(H) mm |
| velikost obrisa | 203(W)×145.5(H) ×11.7(D) mm |
| površino | - |
| svetlost | 350 cd/m² (Typ.) |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| vidni kot | 75/75/60/70 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | - |
| odzivni čas | 8 (Typ.)(Tr+Td) |
| barve zaslona | 16.7M |
| tip svetilke | 12S4P WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | TBD |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
