| PartNumber | AM-800480RSTMQW-TBCH |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 400:1 |
| Barve | 262K |
| Osvetlitev ozadja | 3S10P |
| Vmesnik | LVDS |
| znamka plošče | AMPIRE |
| panelni model | AM-800480RSTMQW-TBCH |
| velikost plošče | 7.0" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 800(RGB)×480, WVGA, 133PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 152.4(W)×91.44(H) mm |
| odprtina okvirja | 155.3(W)×94.3(H) mm |
| velikost obrisa | 174(W)×118(H) ×11.99(D) mm |
| površino | - |
| svetlost | 425 cd/m² (Typ.) |
| kontrastno razmerje | 400:1 (Typ.) (TM) |
| vidni kot | 70/70/70/60 (Typ.)(CR≥10) |
| način prikaza | TN, Normally White, Transmissive |
| najboljši pogled na | 6 o'clock |
| odzivni čas | 5/11 (Typ.)(Tr/Td) |
| barve zaslona | 262K |
| tip svetilke | 3S10P WLED , 40K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | PCAP |
| teža plošče | TBD |
| aplikacija | Industrial |
| signalni vmesnik | LVDS (1 ch, 6-bit) , 40 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
