| PartNumber | AM-800480R2TMQW-U0H |
| Znamka | AMPIRE |
| Velikost | 7.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | LCM , a-Si TFT-LCD |
| Svetlost | |
| CR | 250:1 |
| Barve | 65K |
| Osvetlitev ozadja | WLED |
| Vmesnik | UART |
| proizvajalec | AMPIRE |
| ime modela | AM-800480R2TMQW-U0H |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM , a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 133PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 152.4 × 91.44 (H×V) |
| obris (mm) | 178.5 × 110 × 20.4 (H×V×D) |
| površina okvirja (mm) | 155.3 × 94.3 (H×V) |
| zdravljenje | - |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 250 : 1 (Typ.) (TM) |
| vidni kot | 70/70/60/60 (Typ.)(CR≥10) |
| odgovor | 50 (Typ.)(Tr+Td) ms |
| dober pogled na | - |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 65K 48% NTSC |
| osvetlitev ozadja | WLED , With LED Driver |
| masa | - |
| uporablja za | Industrial |
| hitrost osveževanja | - |
| zaslon na dotik | Without |
| vrsto signala | UART , 8 pins Connector |
| napajanje z napetostjo | 4.6/26.0V (Min./Typ.) |
| maks. ocene | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
