| PartNumber | AM-800480N3TZQW-57H |
| Znamka | AMPIRE |
| Velikost | 5.0 |
| Aplikacija | Industrial Automotiv |
| Resolucija | 800×480 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K |
| Osvetlitev ozadja | 3S6P |
| Vmesnik | |
| proizvajalec | AMPIRE |
| ime modela | AM-800480N3TZQW-57H |
| velikost zaslona | 5.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 800(RGB)×480 (WVGA) 188PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 108 × 64.8 (H×V) |
| obris (mm) | 119.7 × 78.3 × 10.05 (H×V×D) |
| površina okvirja (mm) | 109.6 × 66.4 (H×V) |
| zdravljenje | - |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| odgovor | 30 (Typ.)(Tr+Td) ms |
| dober pogled na | Symmetry |
| način dela | IPS, Normally Black, Transmissive |
| barvna globina | 262K |
| osvetlitev ozadja | 3S6P WLED , 50K hours , With LED Driver |
| masa | - |
| uporablja za | Industrial Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -30 ~ 85 °C Operating Temp.: -30 ~ 85 °C |
