| PartNumber | AM-800480BDTZQW-00H |
| Znamka | AMPIRE |
| Velikost | 4.3 |
| Aplikacija | Industrial Automotiv |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 700:1 |
| Barve | 16.2M |
| Osvetlitev ozadja | WLED |
| Vmesnik | Parallel |
| znamka | AMPIRE |
| model | AM-800480BDTZQW-00H |
| velikost diagonale | 4.3 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 800(RGB)×480 [WVGA] 216PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 95.04(H)×53.856(V) mm |
| obris dim. | 105.3(H)×67(V) mm |
| območje okvirja | 97.9(H)×56.7(V) mm |
| zdravljenje | - |
| svetilnost | 500 cd/m² (Typ.) |
| kontrastno razmerje | 700:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 40 (Typ.)(Tr+Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | Normally Black, Transmissive |
| podpira barvo | 16.2M |
| Izvor svetlobe | WLED [6S2P] , 50K hours , W/O Driver |
| utež | - |
| namenjen za | Industrial Automotive Display |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | Parallel RGB (1 ch, 8-bit) , 40 pins FPC |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -30 ~ 85 °C |
