| PartNumber | AM-800480AZTMQW-50H |
| Znamka | AMPIRE |
| Velikost | 5.0 |
| Aplikacija | Industrial |
| Resolucija | 800×480 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 600:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | 3S6P |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 5.0" |
| resolucija | 800(RGB)×480, WVGA, 188PPI |
| prikazno območje | 108(W)×64.8(H) mm |
| velikost obrisa | 119.7(W)×78(H) ×6.1(D) mm |
| svetlost | 1000 cd/m² (Typ.) |
| vidni kot | 75/75/70/60 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 16.7M 47% NTSC |
| pogostost | 60Hz |
| utež | - |
| panelni model | AM-800480AZTMQW-50H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | Antiglare |
| kontrastno razmerje | 600:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 2/6 (Typ.)(Tr/Td) |
| tip svetilke | 3S6P WLED , 50K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial |
