| PartNumber | AM-640480V2TZQW-TA7H |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 640×480 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1200:1 |
| Barve | 262K |
| Osvetlitev ozadja | 4S7P |
| Vmesnik | LVDS |
| znamka plošče | AMPIRE |
| panelni model | AM-640480V2TZQW-TA7H |
| velikost plošče | 5.7" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 640(RGB)×480, VGA, 141PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 115.2(W)×86.4(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 127(W)×98.43(H) ×10.88(D) mm |
| površino | - |
| svetlost | 850 cd/m² (Typ.) |
| kontrastno razmerje | 1200:1 (Typ.) (TM) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| način prikaza | IPS, Normally Black, Transmissive |
| najboljši pogled na | Symmetry |
| odzivni čas | 30 (Typ.)(Tr+Td) |
| barve zaslona | 262K 60% NTSC |
| tip svetilke | 4S7P WLED , 50K hours , With LED Driver |
| pogostost | 60Hz |
| zaslon na dotik | PCAP |
| teža plošče | - |
| aplikacija | Industrial Outdoor High Brightness |
| signalni vmesnik | LVDS (1 ch, 6-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
