| PartNumber | AM-320240N1TMQW-TW0H-A(R) |
| Znamka | AMPIRE |
| Velikost | 5.7 |
| Aplikacija | Industrial |
| Resolucija | 320×240 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 350:1 |
| Barve | 65K/262K |
| Osvetlitev ozadja | 3S7P |
| Vmesnik | |
| proizvajalec | AMPIRE |
| ime modela | AM-320240N1TMQW-TW0H-A(R) |
| velikost zaslona | 5.7 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 320(RGB)×240 (QVGA) 70PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 115.2 × 86.4 (H×V) |
| obris (mm) | 167 × 109 × 14.8 (H×V×D) |
| površina okvirja (mm) | 118.2 × 89.4 (H×V) |
| zdravljenje | - |
| svetilnost | 400 cd/m² (Typ.) |
| kontrastno razmerje | 350 : 1 (Min.) (TM) |
| vidni kot | 70/70/50/70 (Typ.)(CR≥10) |
| odgovor | 15/35 (Typ.)(Tr/Td) ms |
| dober pogled na | 6 o'clock |
| način dela | TN, Normally White, Transmissive |
| barvna globina | 65K/262K 61% NTSC |
| osvetlitev ozadja | 3S7P WLED , No Driver |
| masa | TBD |
| uporablja za | Industrial |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | 4-wire Resistive Touch |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
