| PartNumber | AM-240320GTZQW-02H |
| Znamka | AMPIRE |
| Velikost | 2.8 |
| Aplikacija | Mobile Phone |
| Resolucija | 240×320 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 450:1 |
| Barve | 65K |
| Osvetlitev ozadja | WLED |
| Vmesnik | CPU/RGB/SPI |
| znamka | AMPIRE |
| model | AM-240320GTZQW-02H |
| velikost diagonale | 2.8 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 240(RGB)×320 [QVGA] 141PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 43.2(H)×57.6(V) mm |
| obris dim. | 49(H)×67.5(V) ×4.9(D) mm |
| svetilnost | 280 cd/m² (Typ.) |
| kontrastno razmerje | 450:1 (Typ.) (TM) |
| smer pogleda | Symmetry |
| odzivni čas | 15/20 (Typ.)(Tr/Td) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| način delovanja | MVA, Normally Black, Transmissive |
| podpira barvo | 65K 69% NTSC |
| Izvor svetlobe | WLED [3S2P] , With LED Driver |
| utež | TBD |
| namenjen za | Mobile Phone |
| hitrost sličic | 60Hz |
| plošča na dotik | Without |
| tip vmesnika | CPU/RGB/SPI , 40 pins FPC |
| napajanje | 2.8V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
