| PartNumber | AM-19201200B1TZQW-01-B |
| Znamka | AMPIRE |
| Velikost | 10.1 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1920×1200 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | |
| znamka plošče | AMPIRE |
| velikost plošče | 10.1" |
| resolucija | 1920(RGB)×1200, WUXGA, 224PPI |
| prikazno območje | 216.806(W)×135.504(H) mm |
| velikost obrisa | 243.45(W)×155.2(H) ×9.61(D) mm |
| svetlost | 1000 cd/m² (Typ.) |
| vidni kot | 85/85/85/85 (Typ.)(CR≥10) |
| najboljši pogled na | Symmetry |
| barve zaslona | 16.7M 53% NTSC |
| pogostost | 60Hz |
| utež | - |
| panelni model | AM-19201200B1TZQW-01-B |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | - |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | Normally Black, Transmissive |
| odzivni čas | 25 (Typ.)(Tr+Td) |
| tip svetilke | WLED , 50K hours , Without Driver |
| zaslon na dotik | Without |
| aplikacija | Industrial Outdoor High Brightness |
| AM-1280800N2TZQW-T48H | AMPIRE | 10.1 | 1280×800 |
| AM-19201200B1TZQW-T00 | AMPIRE | 10.1 | 1920×1200 |
| B101AW01 V2 HW5A | AUO | 10.1 | 1024×576 |
| B101EW02 V0 | AUO | 10.1 | 1280×720 |
| B101UAN01.7 HW2A | AUO | 10.1 | 1920×1200 |
| B101UAN02.1 | AUO | 10.1 | 1920×1200 |
| B101UAN07.0 | AUO | 10.1 | 1200×1920 |
| LTN101AL03-801 | Samsung | 10.1 | 1280×800 |
| VVX10F002A00 | Panasonic | 10.1 | 1920×1200 |
| VVX10F011B00 | Panasonic | 10.1 | 1920×1200 |
