| PartNumber | AM-1024768TTMQW-T00H |
| Znamka | AMPIRE |
| Velikost | 10.4 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 900:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka | AMPIRE |
| model | AM-1024768TTMQW-T00H |
| velikost diagonale | 10.4 inch |
| vrsta | a-Si TFT-LCD, LCM |
| slikovnih pik | 1024(RGB)×768 [XGA] 123PPI |
| konfiguracijo | RGB Vertical Stripe |
| aktivno območje | 211.2(H)×158.4(V) mm |
| obris dim. | 236(H)×176.9(V) ×7.9(D) mm |
| območje okvirja | 214.8(H)×162.0(V) mm |
| zdravljenje | Antiglare |
| svetilnost | 280 cd/m² (Typ.) |
| kontrastno razmerje | 900:1 (Typ.) (TM) |
| smer pogleda | 6 o'clock |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| vidni kot | 75/75/75/75 (Typ.)(CR≥10) |
| način delovanja | TN, Normally White, Transmissive |
| podpira barvo | 262K/16.7M |
| Izvor svetlobe | WLED [4 strings] , 30K hours , With LED Driver |
| utež | 290g (Max.) |
| namenjen za | Industrial |
| hitrost sličic | 60Hz |
| plošča na dotik | 4-wire Resistive Touch |
| tip vmesnika | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| napajanje | 3.3V (Typ.) |
| okolju | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
