| PartNumber | AM-1024768R7TNQW-T00H |
| Znamka | AMPIRE |
| Velikost | 12.1 |
| Aplikacija | Industrial |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD , LCM |
| Svetlost | |
| CR | 800:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 9S3P |
| Vmesnik | LVDS |
| znamka plošče | AMPIRE |
| velikost plošče | 12.1" |
| resolucija | 1024(RGB)×768, XGA, 105PPI |
| prikazno območje | 245.76(W)×184.32(H) mm |
| velikost obrisa | 279(W)×209(H) ×11.2(D) mm |
| svetlost | 510 cd/m² (Typ.) |
| vidni kot | 80/80/80/80 (Typ.)(CR≥10) |
| najboljši pogled na | - |
| barve zaslona | 262K/16.7M |
| pogostost | 60Hz |
| teža plošče | - |
| signalni vmesnik | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| vhodna napetost | 3.3V (Typ.) |
| okolju | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panelni model | AM-1024768R7TNQW-T00H |
| vrsta plošče | a-Si TFT-LCD , LCM |
| slikovnih pik | RGB Vertical Stripe |
| odprtina okvirja | - |
| površino | - |
| kontrastno razmerje | 800:1 (Typ.) (TM) |
| način prikaza | TN, Normally White, Transmissive |
| odzivni čas | 16 (Typ.)(Tr+Td) |
| tip svetilke | 9S3P WLED , 50K hours , Without Driver |
| zaslon na dotik | PCAP |
| aplikacija | Industrial |
