| PartNumber | AA104XN11 |
| Znamka | Mitsubishi |
| Velikost | 10.4 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1024×768 |
| Sestava | a-Si TFT-LCD, LCM |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | WLED |
| Vmesnik | LVDS |
| znamka plošče | Mitsubishi |
| panelni model | AA104XN11 |
| velikost plošče | 10.4" |
| vrsta plošče | a-Si TFT-LCD, LCM |
| resolucija | 1024(RGB)×768, XGA, 123PPI |
| slikovnih pik | RGB Vertical Stripe |
| prikazno območje | 211.2(W)×158.4(H) mm |
| odprtina okvirja | - |
| velikost obrisa | 230(W)×180.2(H) mm |
| površino | - |
| svetlost | 1300 cd/m² (Typ.) |
| kontrastno razmerje | 1000:1 (Typ.) (TM) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10) |
| način prikaza | SWV, Normally Black |
| najboljši pogled na | Symmetry |
| odzivni čas | - |
| barve zaslona | 262K/16.7M 70% NTSC |
| tip svetilke | WLED , 100K hours , Without Driver |
| pogostost | 60Hz |
| zaslon na dotik | Without |
| teža plošče | - |
| aplikacija | Industrial Outdoor High Brightness |
| signalni vmesnik | LVDS (1 ch, 6/8-bit) |
| okolju | Operating Temp.: -30 ~ 80 °C ; Storage Temp.: -40 ~ 80 °C ; Vibration Level: 6.8G (66.64 m/s²) |
