| PartNumber | AA070TA11 |
| Znamka | Mitsubishi |
| Velikost | 7.0 |
| Aplikacija | Industrial Outdoor H |
| Resolucija | 1280×768 |
| Sestava | LCM, a-Si TFT-LCD |
| Svetlost | |
| CR | 1000:1 |
| Barve | 262K/16.7M |
| Osvetlitev ozadja | 2 |
| Vmesnik | |
| proizvajalec | Mitsubishi |
| ime modela | AA070TA11 |
| velikost zaslona | 7.0 inch |
| vrsto zaslona | LCM, a-Si TFT-LCD |
| število slikovnih pik | 1280(RGB)×768 (WXGA) 214PPI |
| ureditev | RGB Vertical Stripe |
| aktivna površina (mm) | 151.68 × 91.01 (H×V) |
| obris (mm) | 169.8 × 109.7 (H×V×D) |
| površina okvirja (mm) | 155.1 × 94.4 (H×V) |
| zdravljenje | Antiglare, Hard coating (3H) |
| svetilnost | 1000 cd/m² (Typ.) |
| kontrastno razmerje | 1000 : 1 (Typ.) (TM) |
| vidni kot | 88/88/88/88 (Typ.)(CR≥10) |
| odgovor | 12/12 (Typ.)(Tr/Td) ms |
| dober pogled na | Symmetry |
| način dela | SWV, Normally Black, Transmissive |
| barvna globina | 262K/16.7M 49% NTSC |
| osvetlitev ozadja | 2 strings WLED , 100K hours , No Driver |
| masa | 200g (Typ.) |
| uporablja za | Industrial Outdoor High Brightness Automotive Display |
| hitrost osveževanja | 60Hz |
| zaslon na dotik | Without |
| Storage Temp.: -40 ~ 80 °C Operating Temp.: -40 ~ 80 °C ; Vibration Level: 6.8G (66.64 m/s²) |
